Sensing range 0.2 to 3 m 0.656 to 9.843 ft
(0.05 to 1 m 0.164 to 3.281 ft when set to SHORT)
(Note) The sensing range is the possible setting distance between the emitter and the receiver.
Beam pitch 25 mm 0.984 in
Number of beam channels 5 beam channels
Sensing object ø35 mm ø1.378 in or more opaque object
(completely beam interrupted object)
Supply voltage 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less
Power consumption Emitter: 0.5 W or less
Receiver: 0.8 W or less
(Note) Obtain the current consumption by the following equation.
Current consumption = Power consumption / Supply voltage
(e.g.) When the supply voltage is 12 V, the current consumption of the emitter is
0.5 W / 12 V ≈ 0.042 A = 42 mA
Output NPN open-collector transistor
- Maximum sink current: 100 mA
- Applied voltage: 30 V DC or less (between output and 0 V)
- Residual voltage: 1 V or less (at 100 mA sink current), 0.4 V or less (at 16 mA sink current)
