Installation Non-flush
Sensing side diameter Ø12mm
Sensing distance 8mm
Hysteresis(distance) Max. 10% of sensing distance
Standard sensing target 25×25×1mm(iron)
Response frequency 400Hz
Unit weight (packaged weight) ≈ 62 g (≈ 74 g)
Indicator Operation indicator (red LED)
Power supply 12 - 24 VDC(ripple P-P: ≤ 10 %), operating voltage: 10 - 30 VDC
Current specification Current consumption: Max. 10mA
Control output ≤ 200 mA
Residual voltage Max. 1.5V
Protection circuit Surge protection circuit, output short over current protection circuit, reverse polarity protection circuit
Insulation resistance ≥ 50 MΩ (500 VDC megger)
Dielectric strength 1,500 VAC~ 50/60Hz for 1 minute
Vibration 1.0 mm amplitude at frequency of 10 to 55 Hzin each X, Y, Z direction for 2 hours
Shock 500 m/s² (≈ 50 G) in each X, Y, Z direction for 3 times
Environment_Ambient temperature -25 to 70 ℃, storage: -30 to 80 ℃ (no freezing or condensation)
Environment_Ambient humidity 35 to 95 %RH, storage: 35 to 95 %RH (no freezing or condensation)
Protection structure IP67(IEC standard)
Connection Cable type
Cable Standard/material Standard type cable (black): polyvinyl chloride (PVC)
Material Case/Nut: nickel plated brass (DIA. of sensing side Ø 8 mm connector type case: SUS303), washer: nickel plated iron, sensing side: PBT
